The compact DX20BF00-04 semi-horn loaded 3/4" silk dome tweeter from Peerless achieves a remarkably low resonant frequency for its size by using a wide surround and large resonant chamber. With smooth response and low distortion, this is an excellent choice for smaller 2-way designs and car audio systems.
Key Features
Matched Pair
Compatible Jig Insert. TJ-2-67MM
Triple ferrite motor improves power handling over similar neodymium designs
Extremely flat response from 1,500 Hz to 20,000 Hz up to 30° off axis
The deep magnet design creates a large resonant chamber for a lower Fs
Semi horn loading the dome improves efficiency and controls dispersion
Brand | Peerless by Tymphany |
Model | DX20BF00-04 |
Part Number | 264-1472 |
UPC | 848864044842 |
Unit of Measure | Each |
Weight | 0.35 |
Product Specifications | |
Cone / Dome Diameter | 0.75" |
Cutout Diameter | 1.91 |
Tweeter Type | Soft Dome |
Power Handling (RMS) | 60 Watts |
Impedance | 4Ω |
Frequency Response | 2,500 to 20,000Hz |
Sensitivity | 86.9dB 2.83V/1m |
Thiele-Small Parameters | |
Resonant Frequency (Fs) | 822.1Hz |
DC Resistance (Re) | 2.81Ω |
Voice Coil Inductance (Le) | 0.01mH |
Mechanical Q (Qms) | 2.24 |
Electromagnetic Q (Qes) | 2.93 |
Total Q (Qts) | 1.27 |
Mounting Information | |
Overall Outside Diameter | 2.6" |
Depth | 1.38" |
