Nominal Diameter | 18" |
Bolt Circle Diameter | 17.3 |
Power Handling (RMS) | 800 Watts |
Power Handling (MAX) | 1600 Watts |
Impedance | 8Ω |
Frequency Response | 34 to 1,000Hz |
Sensitivity | 96dB 2.83V/1m |
Voice Coil Diameter | 4" |
Thiele-Small Parameters | |
Resonant Frequency (Fs) | 35Hz |
DC Resistance (Re) | 5.8Ω |
Voice Coil Inductance (Le) | 1.8mH |
Mechanical Q (Qms) | 4.85 |
Electromagnetic Q (Qes) | 0.55 |
Total Q (Qts) | 0.51 |
Compliance Equivalent Volume (Vas) | 5.9ft³ |
BL Product (BL) | 20.5T·m |
Diaphragm Mass Inc. Airload (Mms) | 220g |
Maximum Linear Excursion (Xmax) | 11mm |
Surface Area of Cone (Sd) | 1210cm² |
Materials of Construction | |
Cone Material | Coated Paper |
Voice Coil Wire Material | Copper |
Voice Coil Former | Fiberglass |
Basket / Frame Material | Cast Aluminum |
Magnet Material | Ferrite |
Mounting Information | |
Overall Outside Diameter | 18" |
Baffle Cutout Diameter | 16.6" |
Depth | 7.75" |
# Mounting Holes | 8 |
