The JDT-6802 1" Textile Dome Tweeter is a solid choice for a DIY build or as a replacement in existing speakers.

Key Features

  • 1200Hz Fs means lower crossover points with larger woofers
  • 1" Textile dome will last forever and has no resonance peaks or break-up modes
  • Matched Pair
  • 1lbs.

Product Details

BrandJDT
ModelJDT-6802
Part Number299-4356
UPC848864074207
Unit of MeasureEach
Weight1.1

Product Specifications

Power Handling (RMS)40 Watts
Power Handling (MAX)80 Watts
Impedance
Frequency Response1,600 to 20,000Hz
Sensitivity89dB 2.83V/1m

Thiele-Small Parameters

Resonant Frequency (Fs)798.4Hz
DC Resistance (Re)5.199Ω

Materials of Construction

Cone MaterialSoft Dome
Basket / Frame MaterialPolymer
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter4.375 x 3.5"
Baffle Cutout Diameter3.625"
Depth1.5"
# Mounting Holes4

JDT-6802 1" Textile Dome Tweeter 8 Ohm. (Matched Pair)

SKU: JDT-6802-MP
$9.99Price
